CSS Pixel Art Generator

Simple PHP CLI script to turn a JPEG image into a single div masterpiece using box-shadow to generate pixels.

Requirements

• PHP CLI
• Composer
• GD

Installation

• Clone repo locally
• Run composer install within the project root directory
• Make the pixel_art file executable

Using

To use, run the following in the command line:

./pixel_art path_to_jpeg_file.jpg

An HTML file with the same name but an .html extension will be generated within the dist directory. Open in any modern browser.

You can change the size of the CSS pixel blocks by changing the $css_block_size value. The script will read every $image_block_sizeth pixel from the image. Lowering this number will result in slower generation times and more box shadows.

Examples

This is the original (resized) image:

Using a 20:1 pixel ratio by setting image and pixel box size to 20, using a total of 468 box shadows:

More box shadows using a 10:1 ratio. Total box shadows is 1,820!

Finally, a 1:1 pixel ratio, resulting in a whopping 177,675 box shadows!:

Note, the examples here are screen shots taken from the resulting HTML page, as that kind of CSS isn't possible here.

Caveats

Due to some browsers not handling too many box shadows on a single element, be careful when using either very large images, or very small pixel settings as your browser may not cope well.

Future Improvements

This is only a very simple script with no error handling or any other nice things that you would expect. Things I'll be adding are:

• Error checking for the various things that could go wrong
• Support for image types other than JPEG
• Make available through a web server and not just a CLI script
  • Possibly add some level of caching here to prevent abuse of any public endpoint
• Return/echo the HTML and CSS code rather than always save to file
